2022/23 Argon 18 E-117 Tri Disc SRAM Force 22

$3,600.00 USD

Color: Black
Size

For many, the E-117 Tri Disc is the obvious choice for their first dedicated triathlon bike. And since aspiring triathletes don’t always come from a cycling background, disc brakes provide increased confidence as they dial-in their TT position. The E-117 Tri Disc will also prove to be a great choice for more experienced triathletes eager to own a reasonably priced triathlon bike, which they can build up by investing in race-day spec of their choice, such as high-end carbon wheels.

Geometry

XXS44-46 XS47-50 S51-53 M54-56 L57-59 XL60-62
A Seat tube Height cm
46.1 50.0 51.6 54.6 57.3
B Seat tube angle deg
78.0 78.0 78.0 78.0 78.0
C Head Tube Angle deg
72.0 72.0 72.0 72.0 72.0
D Top tube length cm
49.2 50.4 51.7 52.7 54.5
E Chain stay length cm
41.3 41.3 41.3 41.3 41.3
F Wheelbase cm
97.6 99.0 100.4 101.8 103.8
G BB Drop cm
7.0 7.0 7.0 7.0 7.0
H1 Head Tube Length 3D (0mm) cm
8.4 9.5 11.1 13.9 16.6
H2 Head Tube Length 3D (15mm) cm
9.9 11.0 12.6 15.4 18.1
H3 Head Tube Length 3D (25mm) cm
10.9 12.0 13.6 16.4 19.1
I Stand Over Height cm
73.0 76.2 77.7 80.5 83.1

Fit

(Stack and Reach)

XXS44-46 XS47-50 S51-53 M54-56 L57-59 XL60-62
J Stack 3D (0mm) cm
49.1 50.1 51.6 54.3 56.8
J Stack 3D (15mm) cm
50.5 51.5 53.0 55.7 58.3
J Stack 3D (25mm) cm
51.5 52.5 54.0 56.7 59.2
K Reach 3D (0mm) cm
38.5 39.5 40.5 40.9 42.2
K Reach 3D (15mm) cm
38.0 39.0 40.0 40.5 41.7
K Reach 3D (25mm) cm
37.7 38.7 39.7 40.1 41.4

Saddle Height Min cm

58.6 62.5 64.1 67.1 69.8

Saddle Height Max cm

78.1 82.0 83.6 86.6 89.3
