- Frame: Cervélo S5 Carbon Frame
- Fork: Cervélo All-Carbon Bayonet Fork
- Groupset: Shimano Dura-Ace Di2 R9270 2×12-Speed
- Shifters: Shimano Dura-Ace Di2 ST-R9270
- Front Derailleur: Shimano Dura-Ace Di2 FD-R9250
- Rear Derailleur: Shimano Dura-Ace Di2 RD-R9250
- Crankset: Shimano Dura-Ace FC-R9200, 52/36T
- Bottom Bracket: CeramicSpeed BBRight for Shimano
- Cassette: Shimano Dura-Ace CS-R9200, 11-34T, 12-Speed
- Chain: Shimano CN-M9100 12-Speed
- Brakes: Shimano Dura-Ace Hydraulic Disc
- Brake Rotors: Shimano RT-MT900 CenterLock, 160mm Front / 160mm Rear
- Handlebar: Cervélo HB19 Carbon Integrated Cockpit
- Stem: Cervélo HB19 Integrated
- Seatpost: Cervélo SP34 Carbon Aero
- Saddle: Selle Italia Novus Boost Evo SuperFlow Carbon
- Headset: FSA IS2 Integrated
- Tires: Vittoria Corsa Pro TLR G2.0, 700×29c
- Wheelset: Reserve 57TA / 64TA Carbon with DT Swiss 180 Hubs
- Pedals: Not Included
- Weight: Approximately 7.1 kg (Varies by Size)
48 cm: Rider Height: 5'2"–5'6" | Wheel Size: 700C | Reach: 367mm | Stack: 496mm | Top Tube: 520mm | Seat Tube: 432mm | Head Tube: 69mm | Head Tube Angle: 71.6° | Seat Tube Angle: 73.8° | Chainstay: 405mm | Wheelbase: 974mm | Bottom Bracket Drop: 72.5mm | Standover Height: 694mm
51 cm: Rider Height: 5'5"–5'9" | Wheel Size: 700C | Reach: 376mm | Stack: 521mm | Top Tube: 535mm | Seat Tube: 463mm | Head Tube: 90mm | Head Tube Angle: 72.3° | Seat Tube Angle: 73.5° | Chainstay: 405mm | Wheelbase: 981mm | Bottom Bracket Drop: 72.5mm | Standover Height: 719mm
54 cm: Rider Height: 5'8"–5'11" | Wheel Size: 700C | Reach: 384mm | Stack: 545mm | Top Tube: 551mm | Seat Tube: 496mm | Head Tube: 114mm | Head Tube Angle: 73.0° | Seat Tube Angle: 73.5° | Chainstay: 405mm | Wheelbase: 990mm | Bottom Bracket Drop: 70mm | Standover Height: 750mm
56 cm: Rider Height: 5'10"–6'1" | Wheel Size: 700C | Reach: 392mm | Stack: 568mm | Top Tube: 567mm | Seat Tube: 519mm | Head Tube: 137mm | Head Tube Angle: 73.0° | Seat Tube Angle: 73.5° | Chainstay: 405mm | Wheelbase: 1007mm | Bottom Bracket Drop: 70mm | Standover Height: 775mm
58 cm: Rider Height: 6'0"–6'3" | Wheel Size: 700C | Reach: 401mm | Stack: 591mm | Top Tube: 583mm | Seat Tube: 542mm | Head Tube: 161mm | Head Tube Angle: 73.0° | Seat Tube Angle: 73.5° | Chainstay: 405mm | Wheelbase: 1023mm | Bottom Bracket Drop: 67.5mm | Standover Height: 800mm
61 cm: Rider Height: 6'2"–6'6" | Wheel Size: 700C | Reach: 409mm | Stack: 611mm | Top Tube: 599mm | Seat Tube: 575mm | Head Tube: 183mm | Head Tube Angle: 73.0° | Seat Tube Angle: 73.5° | Chainstay: 405mm | Wheelbase: 1040mm | Bottom Bracket Drop: 67.5mm | Standover Height: 826mm
- Wheel Brand: Reserve
- Wheel Model: Reserve 57TA Front / Reserve 64TA Rear
- Wheel Size: 700C
- Rim Material: Carbon Fiber
- Rim Depth: 57mm Front / 64mm Rear
- Internal Width: 25mm
- External Width: 35mm
- Hub: DT Swiss 180
- Spokes: Sapim CX-Ray
- Tire Compatibility: Tubeless & Clincher Compatible
- Axle Compatibility: 12×100mm Front / 12×142mm Rear
- Tubeless Ready: Yes
- Approx. Weight: Approximately 1,520g (Wheelset)
