General

FrameRansom Carbon / IMP Technology / HMX Main Frame BB92 / Alloy SL 6011 swingarm VLK Virtual 4 Link kinematic 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj. SW dropouts for Boost 12x148mm TBC Trunnion box construction

Weight*14.50 (with tubes)

Maximum Weight Allowed128 kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

Brakes

BrakeShimano XT M8120 4 Piston Disc

RotorsShimano SM-RT76 / 6 Bolt / 203/F and 180/R

Wheels & Tires

WheelsSyncros Revelstoke 2.0 6 Bolt F: 15x110mm, R: 12x148mm Boost 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool

Rear TireMaxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra

Front TireMaxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra

Cockpit

HandlebarSyncros Hixon 1.5 Rise / Alloy 20140D.B. 20mm rise / 8° / 780mm Syncros Pro lock-on grips

HeadsetSyncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm

Accessories

ExtrasFox 38 Fender

Groupset

Chain / BeltSRAM CN GX Eagle

CassetteSRAM GX / XG1275 / 10-52 T

CranksetSRAM GX Eagle DUB Boost 32T

ShiftersSRAM GX Eagle Trigger

Rear DerailleurSRAM GX / Eagle 12 Speed

Chain GuideSCOTT Chainguide

GearingSRAM GX Eagle

Saddle

Seat PostFOX Transfer Performance Elite Dropper Post 31.6mm / S 125mm / M 150mm / L & XL 175mm

SaddleSyncros Kaslo 1.5 Titanium Rails

Suspension

ForkFOX 38 Float Performance Elite Air / FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle 44mm offset / tapered steerer / Reb. Adj. / Lockout / 170mm travel

ShockFOX NUDE TR EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom Ramp Adjust with linear and progressive setting DPS / Reb. Adj. Travel 170-120-Lockout / 205X65mm

Front suspension170mm

Fork typesuspension fork

Fork ManufacturerFox
